MAINBOARD BARU!! BIKIN NGECEZZz... :sweet: :sweet: :sweet:
Foxconn Blood RAGE & Noctua U12P
Berikut adalah gambar-gambar dari motherboard Foxconn Blood Rage, yang dengan Core i7 serta Tri-Channel memory menjadi yang tercepat hingga saat ini. Review sebelumnya bisa dilihat disini : Foxconn X58 Blood Rage New World Record DDR3 Overclock
Berikut gambar-gambar nya :
detilnya:
* Supports the newest Intel® Core TM i7 and CoreTM i7 Extreme (Bloomfield) processors, Socket T (LGA1366)
* Supports QPI 6.4GT/S
* Triple DDR3 1800(**oc)/1600/1333x 3 DIMMs, Max. 12GB
* 4* PCIe2.0 x16, 1* PCIe2.0 x1, 1* PCI
* 1* ATA133, 2* 1394a, 6* SATA II, 2* eSATA 2*SAS
* SONAR X-Fi audio card, Realtek® ALC889, 7.1 channel Audio
* Dual Gigabit LAN support teaming function by Realtek® 8111C
* 12 USB 2.0 ports
Foxconn Quantum Force aims to deliver high performance computing, connectivity and digital enterainment. With more options for accessing and managing other devices, enhanced reliability features and new PC multimedia technologies. Bloodrage is the ideal choice for extreme performance or quantum force. This motherboard is based on the Intel® X58 chipset - providing ultimate performance for today's desktop computers. The Bloodrage supports the latest industry technologies - Intel® Bloomfield series processors and DDR3 1800MHz(via overclocking) memory. 100% SOLID Capacitor design, Ferrite Choke power delivery and Cool Pipe design help to maximize performance and increase reliability. And at the same time, provided the digital audio outputs via S/PDIF OUT and SONAR X-Fi audio card. CREATIVE X-FiTM ,CMSS 3D, EAX4.0 certification, guaratees the highest quality fidelity for games and movies.
Support Intel® Core™ i7 processors
Supports latest Intel® Core™ i7 processors. QuickPath Interconnect technology for more bandwidth between CPU & system. Intel® Turbo Boost Technology for improved single-threaded performance.
Intel® X58 & ICH10R Chipset
The Intel® X58 Express Chipsets support the latest Intel® Core™ i7 processors with FSB QPI 6.4GT/S, including 45nm processors, with its record breaking performance and greater energy efficiency. Intel® X58 chipset, with optimized system memory capabilities, chipset over-speed protection removed for maximum overclocking, providing faster boot and application load times and additional power savings. Intel® X58 chipset also offer options for DDR3 memory support, providing scalable options for users wanting to take advantage of higher memory performance with less power consumption to run next generation applications such as high-definition video and 3D visualization
Note
lease check our CPU compatibility table for full details
Triple Channel DDR3 1800
Supports 3 channel DDR3 memory up to 1800(oc)MHz for unprecedented memory performance. Install up to 12GB of memory with O.C. orientation 3 DIMM sockets onboard.
ATI CrossFireX™ & NVIDIA SLI™support
ATI CrossFireX™ technology harnesses the power of up to 4 ATI graphics cards simultaneously to deliver ultra-smooth 3D graphics.NVIDIA® 3-way SLI™ enables up to 2.8x performance gain over a single GPU and supports full HD gaming.
PCIe Generation 2.0 support
PCI Express Gen2.0 technology doubles the available aggregate bandwidth between PCIe Generation 2 cards and the motherboard. This means a Gen2.0 16-lane (x16) link can provide up to 16GB/s of bandwidth, 8GB/s in each direction. PCIe Gen2.0 is backwards compatible, and so existing PCIe “Gen1” cards can be plugged into Gen2.0 slots. PCI Express Gen2.0 technology doubles the available aggregate bandwidth between PCIe Generation 2 cards and the motherboard. This means a Gen2.0 16-lane (x16) link can provide up to 16GB/s of bandwidth, 8GB/s in each direction. PCIe Gen2.0 is backwards compatible, and so existing PCIe “Gen1” cards can be plugged into Gen2.0 slots.
Quantum BIOS
Quantum BIOS provides new features and enhancements for overclocking including context-driven menus, more detailed memory configurations and enhanced quad-core overclocking support
4in1 Quantum Cooler
The unique all-copper modular designed 4in1 Quantum Cooler enables effective cooling of the NB, SB and VRM areas. Swap out the NB parts to configure it for air, water or more extreme forms of cooling!
14 phase Hybrid PWM
In addition to the traditional analog PWM, digital phase timing provides accurate phase interleaving standing up to the demands of enthusiasts and overclockers. This finely-tuned digital power management system operates with better power efficiency, a faster and more stable response to changes in power consumption, and higher output current capability to support extreme overclocking.
SONAR X-FI Audio Card
Optimized sound experience that immerses you in the game!
The SONAR X-Fi audio card combines the best audio technologies to restore audio quality after compression and re-encode 2-channel audio into multi-channel digital surround sound. CMSS®-3D support creates surround sound so real you’ll really believe you are in the game, whilst EAX4.0 delivers enhanced sound effects on supporting games. Supports loss-less content protection technology for full-rate HD movie playback from Blu-ray Disc™ or HD-DVD.
SONAR X-FI AUDIO FEATURES
Multi-streaming support for gaming audio & VoIP simultaneously
Accurate 3D positional audio with X-Fi CMSS®-3D
Enhanced gaming sound effects with EAX4.0
X-Fi CRYSTALIZER™ - restores highs and low to music tracks after MP3 compression
Excellent audio fidelity - 108dB DAC SNR/104dB
Loss-less HD audio for Blu-ray Disc™ HD-DVD playback
Selebihnnyua bisa diliat disini:
Code:
http://www.foxconnchannel.com/product/Motherboards/detail_overview.aspx?ID=en-us0000430
Thx 4 gamexeon for the info^^
Dicolong sebagian dari Taken a little from...
Code:
http://www.gamexeon.com/forum/hardware-news/50213-foxconn-blood-rage-noctua-u12p.html
